Veratron / VDO

OceanLink 7" TFT Display

SKU: A2C1865330001
Available
Add to Cart
Years Warranty
Official Distributor

Description

OceanLink Master 7’’ is a multifunction display that lets you monitor engines and related sensor parameters.


The integrated NMEA 2000 gateway lets you acquire engine data also via analog signals or SAE J1939, to then convert and distribute them on NMEA 2000 network.

The display manages up to six resistive sensors, three voltage sensors, two capacitive sensors and one digital alarm and easylink.

Specifications

  • Input supply voltage : 9-32 V DC
  • Nominal voltage : 12V|24V
  • Consumption : ≤ 900 mA
  • Display size : 7"
  • Connectivity : NMEA2000|J1939|EasyLink
  • NMEA2000 inputs : Yes
  • NMEA2000 outputs : Yes
  • J1939 input : 2x
  • EasyLink : 2x
  • Analogue input type : Capacitive (mA)|Resistive (Ω)|Frequency (Hz)|Voltage (V)
  • Resistive signal inputs (Ω) : 6x
  • Capacitive signal inputs (mA) : 2x
  • Voltage signal inputs (V) : 3x
  • Frequency signal inputs (Hz) : 2x
  • Alarm inputs : 1x
  • Alarm outputs : 2x
  • Connector type : Micro-C (NMEA2000)
  • Color : Black

Package content:



1x OceanLink TFT dsplay 7"

1x Connector 1 cable (data+power)

1x Connector 2 cable (data)

1x Black bezel

1x Sun cover

1x EasyLink extension cable

1x Screws

1x Drilling template

1x Manual

1.159,13 €
1.232,43 €
-6%
Add to Cart
