UHF4G Multiband Antenna 3dB

SKU: 14493-432
Available
Add to Cart

Description

Multiband antenna combining the cellular/mobile GSM(2G), UMTS(3G), LTE(4G) and WIFI frequencies.


Frequency range:

LTE: 800/1800/2600

UMTS: 900/1200

GSM: 850/900/1800/1900

WIFI: 2.4/5

WLAN: a/b/g/h/j/n/p/ac

Specifications

  • Application : WLAN 2.4 GHz|WLAN 5 GHz|2G|3G|4G
  • Gain : 3dB
  • Frequency : 790 - 960 MHz|1710 - 2170 MHz|2412 - 2484 MHz|2500 - 2690 MHz
  • Impedance : 50Ω
  • Connector type : N female
  • Mounting & Support : Revolving nut 1"-11
  • Material : Fibreglass
  • Length : 0.44m
  • Product weight : 300g
92,00 €
