Description
The OceanLink Master gauge displays all important engine related data and distributes it to up to 16 52mm satellite gauges.
It also works as a NMEA2000 gateway, by distributing the information from the analog inputs to the digital network.
The LCD display information like position, date and time and - if connected via NMEA2000 network – sea water temperature, depth and speed through water information.
Specifications
- Nominal voltage : 12V|24V
- Connectivity : NMEA2000|J1939|EasyLink
- NMEA2000 inputs : Yes
- NMEA2000 outputs : Yes
- J1939 input : 1x
- EasyLink : 1x
- Resistive signal inputs (Ω) : 2x
- Frequency signal inputs (Hz) : 1x
- Alarm outputs : 1x
- Speed range : 0-14knots/kmh/mph
- Integrated features : GPS antenna
- Connector type : Micro-C (NMEA2000)|AMP superseal plug
- Color : Black
- Diameter : 85mm
Package content:
1x GPS Speedometer gauge
1x Spinlock
1x Power cable
1x Safety instructions
