Raymarine
DST810 Gen2 Smart Transducer
SKU: E70667
Available
Add to Cart
Description
The DST810 is a multi-sensor transducer with depth, speed and temperature sensors.
Plug the DST810 directly into the SeaTalkNg network and receive data on all of your connected instruments, chartplotters and multifunction displays.
DST810 also includes a built-in attitude sensor that measures vessel heel and trim. Combining those measurements together with the ultra-precise readings from its Gen2 paddlewheel sensor, the DST810 provides heel compensated speed through water readings without any additional sensors.
Specifications
- Input supply voltage : 9-16V DC
- Nominal voltage : 12V
- Consumption : < 200mA
- Power : 100W
- Connectivity : NMEA2000|Bluetooth
- NMEA2000 outputs : Yes
- Speed range : 0.3-45knots
- Integrated features : Boat speed (through water)|Heel & Trim
- Frequency : 235kHz
- Connector type : SeaTalkng
- Mounting & Support : Retractable Thru-Hull [P617V (P17)]
- Material : Urethane|Plastic
- Hole diameter : Ø 51mm
