Actisense
NMEA 0183 Buffer
SKU: PRO-NBF-1
Available
Add to Cart
Years
Warranty
Official
Distributor
Description
The Type approved NMEA Buffer PRO-NBF-1 Buffer isolates and buffers NMEA 0183 data, with the power to drive multiple devices.
The NMEA Buffer has ISO-Drive™ technology on the outputs and OPTO-isolation on the input.
Specifications
- Input supply voltage : 9-35 V DC
- Nominal voltage : 12V
- Consumption : 150mA @12 VDC
- Connectivity : NMEA0183
- NMEA0183 inputs : 1x
- NMEA0183 outputs : 6x
- Serial port compatibility : RS422|RS232|RS485|NMEA 0183
- Baud rate : 4800 to 115200 bps
- Connector type : Ethernet (RJ45)
- Type approved : Yes
- Dimensions : 139mm(L)x128mm(W)x27mm(H)
