Veratron / VDO
VMH35-D Multifunction Gauge 85mm
SKU: -
Choose Configuration variant
Add to Cart
Years
Warranty
Official
Distributor
Description
The VMH 35-D is the perfect standalone solution for monitoring your diesel engine.
With a configurable dial scale of 3000 or 4000 RPM, the VMH 35-D is a compact display capable of showing a wide amount of data from your engine, battery, tank, and GPS.
Specific information about your diesel engine is provided together with alarms, either received from the SAE J1939 bus or locally set through the embedded menu.
Both 12V and 24V systems are supported, as well as EasyLink connectivity which allows your dashboard to be expanded with additional VMH 14 satellite displays to always keep your sensitive data under control.
Variants:
B00171201: Without GPS receiver
B00171101: With GPS receiver
Specifications
- Input supply voltage : 9-32V DC
- Nominal voltage : 12V|24V
- Consumption : < 170mA @ 12V
- Connectivity : NMEA2000|J1939|EasyLink
- NMEA2000 inputs : Yes
- NMEA2000 outputs : Yes
- J1939 input : 1x
- EasyLink : 1x
- Data transfer/conversion : J1939 to NMEA2000
- Analogue input type : Resistive (Ω)|Frequency (Hz)
- Resistive signal inputs (Ω) : 2x
- Frequency signal inputs (Hz) : 2x
- Signal resistance range : 0-400Ω
- Alarm outputs : 1x
- Transducer inputs : Speed
- Speed transducer inputs : 1x
- RPM range : 4000rpm
- Connector type : Micro-C (NMEA2000)|Molex MX150
- Diameter : 85mm
