Temperature Sensor 40-120°C / 105-250°F
Veratron / VDO

Veratron / VDO

Temperature Sensor 40-120°C / 105-250°F

SKU: 323-803-001-032D
Available
Add to Cart
Years Warranty
Official Distributor

Description

Coolant temperature sensor with 1pole common ground, warning contact and 1/2"-14 NPTF thread.

Used for: Water, oil, fuel,air.


Sensor not in production.

Limited stock available.

Similar code: 323-803-001-019D

Specifications

  • Nominal voltage : 12V|24V
  • Analogue output type : Resistive (Ω)
  • Signal resistance range : 287.4-22.7Ω
  • Temperature range : 40-120°C/105-250°F
  • Return signal : Common ground
  • Warning contact's range : 108°C±3°C
  • Threads : 1/2" - 14 NPTF
  • Connector type : M4 AMP male 6.3x0.8mm

Documents

53,84 €
