Argodiode Battery Isolator - 3AC Argodiode Battery Isolator - 3AC
Victron Energy

Victron energy

Argodiode Battery Isolator - 3AC

SKU: -
Choose Current variant
Add to Cart
Years Warranty

Description

Diode battery isolators allow simultaneous charging of two or more batteries from one alternator, without connecting the batteries together.

Discharging the accessory battery for example will not result in also discharging the starter battery.


Alternator energize input:

Some alternators need DC voltage on the B+ output to start charging. Obviously, DC will be present when the alternator is directly connected to a battery. Inserting a Diode or FET splitter will however prevent any return voltage/current from the batteries to the B+, and the alternator will not start. The new ‘AC’ diode isolators feature a special current limited energize input that will power the B+ when the engine run/stop switch is closed.

Specifications

  • Nominal voltage : 12V|24V
  • AC inputs : 1
  • Charge outputs : 3
  • Extras : 3 battery outputs|Alternator energize input

Documents

banner
89,28 €
