Raymarine
CPT-S Conical Thru-Hull Transducer 12°
SKU: A80448
Available
Add to Cart
Years
Warranty
Description
The CPT-S family of through hull transducers provides high-resolution sonar imagery and reliable depth recording for Raymarine Element and Axiom chartplotters.
The low-profile design eliminates the need for a fairing block while offering excellent high-speed performance.
FEATURES:
- Supports single High CHIRP sonar with a 25° conical beam
- Available with 0°, 12°, and 20° angled elements to compensate for various hull deadrise angles.
- Integrated seawater temperature sensor
- Up to 900 ft (274 m) depth range
- Includes 10 meter cable
Deadrise angles: 7-17°
Specifications
- Power : 90W
- Depth range : High Chirp: 270m/900ft
- Tilt : 12°
- Frequency : High Chirp [170 to 230kHz]
- Connector type : 9pin 1kW male XDCR
- Mounting & Support : Thru-Hull
- Material : Urethane|Plastic
- Hole diameter : Ø 51mm
Documents
Related products
Package content:
1x CPT-S transducer
1x Hull nut
1x Spacer
1x Rubber washer
1x Documentation
