Actisense
NMEA2000 to NMEA0183 Bi-directional Gateway
SKU: -
Choose Configuration variant
Add to Cart
Years
Warranty
Official
Distributor
Description
Multiple NGW-1 units can be used to multiplex numerous NMEA 0183 devices onto the NMEA 2000 network, using the network as a means of combining and transferring all data from one place to another.
Gateway not in production.
Limited stock available.
Replacement NGX-1-ISO
Specifications
- Input supply voltage : 9.5-35 V DC
- Nominal voltage : 12V|24V
- Consumption : 35mA @ 12 VDC
- Connectivity : NMEA2000|NMEA0183
- NMEA2000 inputs : Yes
- NMEA2000 outputs : Yes
- Serial port compatibility : RS422|RS232|RS485|NMEA 0183
- Baud rate : 4800 to 115200 bps
- Data transfer/conversion : NMEA2000 to NMEA0183
- Connector type : Micro-C (NMEA2000)
- Dimensions : 179mm(L)x46mm(W)x28.5mm(H)
- Product weight : 220g
