Περιγραφή
The push button circuit breaker provides economical circuit protection for 3 to 40 Amp loads when switching is provided elsewhere or not required.
Features:
- Branch circuit breakers - also used for 24-hour circuit protection
- Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels
- Compact design enables high density circuit protection configurations
- Push-to-reset operation
- Trip Free design cannot be held ON during fault current condition
- Optional push button waterproof boot protects circuit breaker in wet environments
- Ignition protected - Safe for installation aboard gasoline powered boats
Circuit breaker type: Thermal trip - manual push button reset only.
Χαρακτηριστικά
- Τάση εισόδου : 32V DC
- Τάση λειτουργίας : 12V|24V
- Extras : Ignition protected
- Σπείρωμα : 1/4 Male quick connect
- Τύπος τοποθέτησης : Front panel mount
- Διαστάσεις : 58.60x35.03x14.50mm
- Βάρος : 0.03kg
