Lecomble & Schmitt

Hydraulic Power Pack RV2

SKU: -
Επιλέξτε Εκδοχή Ρεύματος
Προσθήκη στο Καλάθι

Περιγραφή

Hydraulic power packs with adjustable flow for double rod cylinders.


The power pack RV2 is reversible by changing the polarity on the motor terminals.

Flow adjustment is done through a screw which allows accurate regulation of the time required for lock to lock displacement.

This power pack is fitted with lock valves.



Maximum cylinder capacity: 432 cc

Χαρακτηριστικά

  • Τάση λειτουργίας : 12V|24V
  • Εύρος πίεσης : 30BAR
  • Σταθερό ρεύμα : 25A
  • Flow rate : 0.2-2 L/mn
  • Βάρος : 4.5kg
1.144,09 €
